CPR

Consolidated Patch Report

Introduction

A perl script that takes information from the sources like the following to create a consolidated report in the form of a Excel Spreadsheet (XLSX) with charts:

• A ServiceNow CMDB XLSX extract
• A Server Master XLS list
• Solaris PCA HTML patch report
• Windows WSUS CVS output
• Redhat CVS report

It can me modified to run with more or less sources. It processes the source information into dated files so that trending information can be charted, such as whether patching rates are improving. It also supports reporting on environments based on hostname and CMDB information.

Version

Current version: 0.6.1

See CHANGELOG.md for the list of changes.

License

CC BY-NC-SA 4.0: https://creativecommons.org/licenses/by-nc-sa/4.0/

Help Support Development

If you find this software useful and would like to support its development, please consider buying me a coffee:

https://ko-fi.com/richardatlateralblast

Directory Structure

The following directory structure is used to generate historical data:

top/
cpr.pl
raw/download.csv         (Current Red Hat Satellite CSV)
raw/index.html           (Current PCA HTML report)
raw/wintel_latest.csv    (Current Windows WSUS report)
raw/cmdb.csv             (Current CMDB extract)
raw/master_list.xls      (Current Server Master List)
old/download.csv_MM_YYYY  (Archived Red Hat Satellite CSV)
old/index.html_MM_YYYY    (Archived PCA HTML report)
old/wintel_latest.csv_MM_YYYY (Archived Windows WSUS report)
cpr/sol_MM_YYYY          (Solaris Monthly Patch Information)
cpr/sol_all              (All Solaris Monthly Patch Information)
cpr/lin_MM_YYYY          (Linux Monthly Patch Information)
cpr/lin_all              (All Linux Monthly Patch Information)
cpr/win_MM_YYYY          (Windows Monthly Patch Information)
cpr/win_all              (All Windows Monthly Patch Information)
cpr/xpr_MM_YYYY          (All Monthly Patch Information)
cpr/xpr_all              (All Patch Information)
pci/hosts                A file with a list of PCI host names
exc/hosts                Hosts to exclude
xls/all_report.xlsx      All Report
xls/windows_rpeort.xlsx  Windows Report
xls/linux_report.xlsx    Linux Report
xls/solaris_report.xlsx  Linux Report
xls/pci_report.xlsx      PCI Report

Gathering Information

To generate a report the latest versions of information need to be copied in the relevant locations as detailed above. These files contain data information, which the script will use to process the information into date based files which it will then use to generate the report with historical/trending information.

For example:

The latest ServiceNow CMDB extract is copied to raw/cmdb.xlsx

The latest Red Hat Satellite report (eg https://rhelsat/rhn/CSVDownloadAction.do) is copied to raw/download.csv

The latest Server master list is copied to raw/master_list.xls

The latest Solaris PCA HTML report is copied to raw/index.html

The latest WSUS XLS extract is copied to raw/wintel_latest.csv

The name of these files can be modified in the script or manually imported.

PCI hosts

PCI hosts are rated differently to normal hosts. Any outstanding security patches is marked as bad.

The script will try to get information from the CMDB extract regarding whether a host is a PCI host. Hosts can also be manually be added to the pci/hosts file.

For example:

$ cat pci/hosts
pcihost1
pcihost2

Excluding hosts

If there is a need to exclude hosts from the results, this can be done by adding the hostname to exc/hosts. Additionally a reason can be given for excluding the host, which will appear as a comment in the spreadsheet report.

$ cat exc/hosts
host1,Decommissioned
host2,Upgade in progress

Generating Report

The first time the report is run it will take a little longer as it imports the various files and creates historical files to process.

To generate a consolidated patch report of all Operating Systems and environments:

$ cpr.pl -a
Generating xls/all_report.xlsx

To generate a summarised consolidated patch report for everything (this will hide the worksheets for individual operating systems):

$ cpr.pl -a -S
Generating xls/summary_report.xlsx

To produce a traditional percentage based report of everything:

$ cpr.pl -a -S -t
Generating xls/summary_report.xlsx

To generate a report that includes Windows information only:

$ cpr.pl -w
Generating xls/windows_report.xlsx

To generate a report that include Linux information only:

$ cpr.pl -l
Generating xls/linux_report.xlsx

To generate a report that includes Solaris information only:

$ cpr.pl -s
Generating xls/solaris_report.xlsx

To generate a report that includes PCI information only:

$ cpr.pl -p
Generating xls/pci_report.xlsx

Required Packages for Perl Script

The following Perl modules are required:

• HTML::Tagset
• URI
• HTTP::Date
• LWP::MediaTypes
• parent
• Encode
• Test::More
• IO::HTML
• Compress::Raw::Bzip2
• Compress::Raw::Zlib
• IO::Compress::Bzip2
• Encode::Locale
• HTTP::Headers
• HTML::TokeParser
• Archive::Zip
• IO::File
• Storable
• Sub::Uplevel
• Test::Exception
• Carp::Clan
• Bit::Vector
• Date::Calc
• Pod::Escapes
• Test
• Pod::Simple
• Test::Pod
• Devel::Symdump
• Pod::Coverage
• Test::Pod::Coverage
• Test::Inter
• Excel::Writer::XLSX
• Switch
• Time::Piece
• Text::Iconv
• Spreadsheet::XLSX
• Text::CSV
